**NEW RELEASE** 011528 In-Wall 2-Port Gigabit PoE Switch

**NEW RELEASE** 011528 In-Wall 2-Port Gigabit PoE Switch

Part Number: 011528

MSRP: $112.00

Each CyberData device comes with a Two-Year Warranty. Extended Warranty extends your warranty for an additional two years. Already have a CyberData device and want to add a Two-Year Warranty? Please click the link below to register your device first:

http://support.cyberdata.net/register.php


The CyberData In-Wall 2-Port Gigabit PoE Switch is a flush-mount version of our popular desktop device which expands a single PoE network connection into one or two PoE network ports.

Pass through PoE Power

The In-Wall 2-Port Gigabit PoE Switch is powered from a single 802.3at or 802.3af network switch or power source and passes that power through to one or both of the switch ports.

In the basic configuration, one of the Gigabit ports can drive a VoIP phone directly with PoE and the other Gigabit port can be connected to a user’s PC.

No external power supplies are required.

Discreet Mounting

The In-Wall mounting option protects the switch while offering a cleaner drop directly from a standard size single gang wall outlet.

Power
  • Fully compliant to IEEE 802.3af/at standard
  • 1 Power Device (PD) input port 802.3af or 802.3at
  • 2 Power Source Equipment (PSE) output ports 802.3af or 802.3at (dependent on PD input)
  •

    Data
  • All ports are 10/100/1000Mbps (10BASE-T,100BASE-TX,1000BASE-T) auto sensing based upon the port's individual connection
  • Each port has auto MDI-X
  • 802.11q VLAN tagging
  • Automatic address learning, address aging and address migration
  • Supports 9216-byte jumbo frame length
  •

    Notification
  • Link/Status and connection speed LEDs
  •

    Mounting
  • No punch down tool required; RJ45 connector input port
  • Ethernet I/F 10/100/1000 Mbps, Auto MDI-X, RJ45
    Power Distribution
    Input PD input up to 30W:
  • 802.3af @ 15W
  • 802.3at @ 25W
  • Generic PoE Injector up to 30W
  • Internal Circuit Use 2W
    Output* Power available to share between two PSE outputs:
  • 13W with 802.3af input
  • 23W with 802.3at input
  • 28W with generic 30W PoE injector input
  • Operating Range Temperature: -40 degrees C to 55 degrees C (-40 degrees F to 131 degrees F)
    Humidity: 5-95%, non-condensing
    Storage Temperature -40 degrees C to 70 degrees C (-40 degrees F to 158 degrees F)
    Storage Altitude Up to 15,000 ft. (4573 m)
    Dimensions** Length: 2.76 inches [70 mm]
    Width: 3.90 inches [99 mm]
    Height: 4.57 inches [116 mm]
    Weight
    Boxed Weight
    0.56 lbs. [0.25 kg]
    1.0 lbs. [.54 kg]
    Compliance CE: EMC Directive - Class A EN 55032, EN 55035 & EN 61000, LV Safety Directive- EN 62368-1, RoHS Compliant; FCC Part 15 Class A; IEEE 802.3 Compliant
    Warranty 2 years limited
    Part Number 011528

    *Either one or both of the PSE outputs can provide PoE power as long as the overall PSE output wattage is 2W less than the PD input.

    **Dimensions are measured from the perspective of the product being upright with the front of the product facing you.


    Typical Installation

    Use Case Installation – Power Two 802.3af Cameras at Hallway Corner

    Typical Wall Installation

    Dimensions
    Documentation
    Description Date
    PDF Datasheet DATE:5/19/21
    PDF Quick-Reference Placemat DATE:5/20/21
