010807 PoweredUSB 4-Port 2.0 Hub

Part Number: 010807

Contact Us For Pricing



The CyberData 4-port PoweredUSB Hub with external power supply provides a simple and affordable way to add up to four PoweredUSB ports to your PC that are controlled by the PC's Stand-by/Wake commands. With this PoweredUSB add-on hub, it is easy to connect devices that need more than the standard USB interface supplied 500mA of +5 volts. The 4-port hub includes plug-n-play installation, three +12V ports (1.5A each) and one +24V port (2.3A), multiple power supply options, peripheral power control by PC stand-by/wake commands, short-circuit and over-current protection, LED indicators to show power and USB 2.0 status, instruction manual, and two-year warranty. The 4-Port hub is also designed to mount into Dell's Retail Integrator system.

Advanced DataLine Protection
The CyberData PoweredUSB hub is designed with circuitry that protects the communcation and power lines from damage when hot plugging non-PoweredUSB compliant peripherals.

  • Up to 4 ports
  • +12V and +24V connector options
  • Advanced DataLine protection
  • PoweredUSB.Org .08G compliant
  • Windows "green mode" support
  • USB 2.0 Compliant
  • PoweredUSB .08g Compliant
PoweredUSB Ports 4
PoweredUSB Power Output (std) 1@24V 2.3A
3@12V 1.5A each
(All ports support standard "A" type +5V USB connection)
Port Baud Rates 480Mbps, 12Mbps, 1.5Mbps
Power Input 24 VDC
External LEDs Power, Link, Status
PoweredUSB Power Output* (std) 1@24V 2.3A, 3@12V 1.5A each
Dimensions 3.75 inches [95.25 mm] Length
4.25 inches [107.95 mm] Width
1.75 inches [44.45 mm] Height

Weight/
Boxed Weight

1.0 lbs. (0.45 kg)
2.6 lbs. (1.15 kg)
Compliance CE; EMC Directive - Class A EN 55032 & EN 55024, LV Safety Directive- EN 60950-1, RoHS Compliant, FCC; Part 15 Class A, Industry Canada; ICES-3 Class A, IEEE 802.3 Compliant
Warranty 2 years limited
Part Number 010807


Typical Installation


Jumpers (JP1 and JP2) on the PCBA

Documentation
Description Date
PDF Datasheet DATE:8/15/18
PDF Operation Guide DATE:7/2/24
PDF Quick Reference (010776) DATE:4/13/06
PDF Quick Reference (010807) DATE:8/31/11
