011280 InformaCast Enabled Paging Adapter

Part Number: 011280

MSRP: $455.00

Each CyberData device comes with a Two-Year Warranty. Extended Warranty extends your warranty for an additional two years. Already have a CyberData device and want to add a Two-Year Warranty? Please click the link below to register your device first:

http://support.cyberdata.net/register.php

CyberData’s Try & Buy program allows you to order QTY (1) of any SIP device and try it for 30 days to determine if it will meet your needs. When “Try and Buy" is selected, we charge on shipment and we will apply a credit IF the product is returned through our RMA process within 30 days, in good condition in its original packaging.

Once returned and upon inspection, CyberData will apply the credit to your credit card, less any shipping and handling charges that CyberData incurs. No returns are accepted after 30 days under our Try & Buy program.

Need help configuring your devices?

The CyberData InformaCast® Enabled Paging Adapter is for use with Singlewire's InformaCast paging and emergency notification software. The Paging Adapter provides a direct connection to legacy analog paging systems enabling InformaCast paging events to be broadcast.

  • Compatible with Singlewire InformaCast v12.1, including support for downloading SIP credentials from InformaCast
  • Supports Singlewire InformaCast High Quality Audio
  • Capable of receiving Singlewire InformaCast, SIP, and multicast messages
  • Support for InformaCast resiliency
  • Support for Cisco SRST resiliency
  •

  • Compatible with most analog amplifiers in the market
  • Supports audio prioritization, including 10 multicast paging groups
  • Loud/Night ringer function - second SIP extension
  • 9 user-uploadable page messages
  • Supports delayed pages with call buffering
  • Support for security code to prevent unwanted SIP calls
  • Can receive pages directly from Poly phones as well as other devices that can send standard multicast
  • Sense input capable of generating events or SIP calls
  •

  • Built-in diagnostics
  • Line-in for background music
  • Line-out connector
  • Remote amp fault sensor
  • Audio controlled relay/remote amplifier enable
  • DTMF entries for analog paging zones
  • Rack mountable
  •

  • TLS 1.2 and SRTP enhanced security for IP Endpoints in a local or cloud-based environment
  • HTTPS or HTTP web based configuration - HTTPS is enabled by default
  • Autoprovisioning via HTTPS, HTTP or TFTP
  • Configurable event generation for device health and status monitoring
  • 802.11q VLAN tagging
  • HTTP command interface
  • Ethernet I/F 10/100 Mbps
    Protocol SIP RFC 3261 Compatible
    Notification Software Singlewire InformaCast v4.0 and above
    Power Input PoE 802.3af or 48VDC
    Line In:
    Input Signal Amplitudes
    Input Impedance

    2.0 VPP Maximum
    10k Ohm
    Line Out:
    Output Signal Amplitudes
    Output Level
    Total Harmonic Distortion
    Output Impedance

    2.0 VPP Maximum
    +2dBm nominal
    0.5% maximum
    10k Ohm
    Page Port Output Balanced 600 Ohm 5VPP
    Payload Types G.711 a-law, G.711μ-law, G.722 and G.729
    Network Security TLS/SSL 1.2 and SRTP
    Operating Range Temperature: -40 degrees C to 55 degrees C (-40 degrees F to 131 degrees F)
    Humidity: 5-95%, non-condensing
    Storage Temperature -40 degrees C to 70 degrees C (-40 degrees F to 158 degrees F)
    Storage Altitude Up to 15,000 ft. (4573 m)
    Dimensions* Length: 6.11 inches [155.19 mm]
    Width: 4.05 inches [102.87 mm]
    Height: 1.15 inches [29.21 mm]
    Weight
    Boxed Weight
    1.2 lbs. [0.54 kg]
    1.8 lbs. [.82 kg]
    Compliance UL 62368-1, RoHS Compliant, FCC; Part 15 Class A, IEEE 802.3 Compliant; Reference Number for UL: E129569 Vol 4 Sec 1
    Warranty 2 years limited
    Part Number 011280

    *Dimensions are measured from the perspective of the product being upright with the front of the product facing you.

    How do I update my firmware?

    Go to the Downloads tab, click on the serial number range matching your device and download the firmware compatible with it. To update the firmware, unzip the file and log in to the web GUI for the device you are trying to upgrade. Navigate to the Firmware tab and browse for the firmware file you just downloaded. Select and upload that file. Do not reboot, the device will do it for you. For more information, please check your product’s Operations Guide, also available under the Downloads tab.

    PLEASE NOTE: Firmware is not backwards compatible for V3 devices. If you are downgrading or trying to update a pre-V3 device, please contact CyberData’s Technical Support Department first to ensure the device does not get damaged. We also recommend you export a copy of your current configuration BEFORE updating, should a loss of power or another issue occur that would potentially lose your settings.

    Is this device compatible with my service provider or IP-PBX server?

    CyberData VoIP products are compatible with IP-PBX servers that support standard SIP protocol. You can find a full list of IP-PBX servers that CyberData products have been validated on by going to Connecting to Compatible IP-PBX Servers. If you do not see your IP-PBX on this list, feel free to contact CyberData’s Technical Support Department for more information.

    Is this device compatible with my analog amplifier?

    Our page, Connecting to Compatible Analog Amplifiers, portrays a list of third party analog amplifiers that CyberData has validated compatibility. If you do not see your amplifier on the list, please contact CyberData’s Technical Support Department.

    What is multicast?

    IP multicast is a technique for one-to-many communication over a local IP network. IGMP multicast is sent via UDP packets from a multicast server to a multicast receiver. This stream scales to a larger receiver population by not requiring prior knowledge of who or how many receivers there are. Multicast uses network infrastructure efficiently by requiring the source to send a packet only once, even if it needs to be delivered to many receivers. The network replicates the packet in order to reach multiple receivers only when necessary.

    Multicast is a great alternative to SIP registration as it does not require that the recipient of the stream to register as an extension on an IP-PBX server.

    CyberData products support both regular IGMP multicast as well as proprietary Polycom Group Paging.

    Which IP Phones do you recommend for setting up a Peer to Peer SIP call with this device?
    If I wanted to power the device by using the auxiliary power connector, what type of power supply do I need?

    The power connection requires a +48v 380mA (min) power brick. The connector is 2.5mm with a positive center. Cisco's CP-PWR-CUBE-3 power brick is approved.

    For additional support or answers to questions not covered on this page, who should I contact?


    Typical Installation



    Connections

    Description

    The CyberData InformaCast® Enabled Paging Adapter is for use with Singlewire's InformaCast paging and emergency notification software. The Paging Adapter provides a direct connection to legacy analog paging systems enabling InformaCast paging events to be broadcast.

    Features

  • Compatible with Singlewire InformaCast v12.1, including support for downloading SIP credentials from InformaCast
  • Supports Singlewire InformaCast High Quality Audio
  • Capable of receiving Singlewire InformaCast, SIP, and multicast messages
  • Support for InformaCast resiliency
  • Support for Cisco SRST resiliency
  •

  • Compatible with most analog amplifiers in the market
  • Supports audio prioritization, including 10 multicast paging groups
  • Loud/Night ringer function - second SIP extension
  • 9 user-uploadable page messages
  • Supports delayed pages with call buffering
  • Support for security code to prevent unwanted SIP calls
  • Can receive pages directly from Poly phones as well as other devices that can send standard multicast
  • Sense input capable of generating events or SIP calls
  •

  • Built-in diagnostics
  • Line-in for background music
  • Line-out connector
  • Remote amp fault sensor
  • Audio controlled relay/remote amplifier enable
  • DTMF entries for analog paging zones
  • Rack mountable
  •

  • TLS 1.2 and SRTP enhanced security for IP Endpoints in a local or cloud-based environment
  • HTTPS or HTTP web based configuration - HTTPS is enabled by default
  • Autoprovisioning via HTTPS, HTTP or TFTP
  • Configurable event generation for device health and status monitoring
  • 802.11q VLAN tagging
  • HTTP command interface
  • Specs

    Ethernet I/F 10/100 Mbps
    Protocol SIP RFC 3261 Compatible
    Notification Software Singlewire InformaCast v4.0 and above
    Power Input PoE 802.3af or 48VDC
    Line In:
    Input Signal Amplitudes
    Input Impedance

    2.0 VPP Maximum
    10k Ohm
    Line Out:
    Output Signal Amplitudes
    Output Level
    Total Harmonic Distortion
    Output Impedance

    2.0 VPP Maximum
    +2dBm nominal
    0.5% maximum
    10k Ohm
    Page Port Output Balanced 600 Ohm 5VPP
    Payload Types G.711 a-law, G.711μ-law, G.722 and G.729
    Network Security TLS/SSL 1.2 and SRTP
    Operating Range Temperature: -40 degrees C to 55 degrees C (-40 degrees F to 131 degrees F)
    Humidity: 5-95%, non-condensing
    Storage Temperature -40 degrees C to 70 degrees C (-40 degrees F to 158 degrees F)
    Storage Altitude Up to 15,000 ft. (4573 m)
    Dimensions* Length: 6.11 inches [155.19 mm]
    Width: 4.05 inches [102.87 mm]
    Height: 1.15 inches [29.21 mm]
    Weight
    Boxed Weight
    1.2 lbs. [0.54 kg]
    1.8 lbs. [.82 kg]
    Compliance UL 62368-1, RoHS Compliant, FCC; Part 15 Class A, IEEE 802.3 Compliant; Reference Number for UL: E129569 Vol 4 Sec 1
    Warranty 2 years limited
    Part Number 011280

    *Dimensions are measured from the perspective of the product being upright with the front of the product facing you.

    FAQs

    How do I update my firmware?

    Go to the Downloads tab, click on the serial number range matching your device and download the firmware compatible with it. To update the firmware, unzip the file and log in to the web GUI for the device you are trying to upgrade. Navigate to the Firmware tab and browse for the firmware file you just downloaded. Select and upload that file. Do not reboot, the device will do it for you. For more information, please check your product’s Operations Guide, also available under the Downloads tab.

    PLEASE NOTE: Firmware is not backwards compatible for V3 devices. If you are downgrading or trying to update a pre-V3 device, please contact CyberData’s Technical Support Department first to ensure the device does not get damaged. We also recommend you export a copy of your current configuration BEFORE updating, should a loss of power or another issue occur that would potentially lose your settings.

    Is this device compatible with my service provider or IP-PBX server?

    CyberData VoIP products are compatible with IP-PBX servers that support standard SIP protocol. You can find a full list of IP-PBX servers that CyberData products have been validated on by going to Connecting to Compatible IP-PBX Servers. If you do not see your IP-PBX on this list, feel free to contact CyberData’s Technical Support Department for more information.

    Is this device compatible with my analog amplifier?

    Our page, Connecting to Compatible Analog Amplifiers, portrays a list of third party analog amplifiers that CyberData has validated compatibility. If you do not see your amplifier on the list, please contact CyberData’s Technical Support Department.

    What is multicast?

    IP multicast is a technique for one-to-many communication over a local IP network. IGMP multicast is sent via UDP packets from a multicast server to a multicast receiver. This stream scales to a larger receiver population by not requiring prior knowledge of who or how many receivers there are. Multicast uses network infrastructure efficiently by requiring the source to send a packet only once, even if it needs to be delivered to many receivers. The network replicates the packet in order to reach multiple receivers only when necessary.

    Multicast is a great alternative to SIP registration as it does not require that the recipient of the stream to register as an extension on an IP-PBX server.

    CyberData products support both regular IGMP multicast as well as proprietary Polycom Group Paging.

    Which IP Phones do you recommend for setting up a Peer to Peer SIP call with this device?
    If I wanted to power the device by using the auxiliary power connector, what type of power supply do I need?

    The power connection requires a +48v 380mA (min) power brick. The connector is 2.5mm with a positive center. Cisco's CP-PWR-CUBE-3 power brick is approved.

    For additional support or answers to questions not covered on this page, who should I contact?
