Part Number: 011489

MSRP: $821.00

Each CyberData device comes with a Two-Year Warranty. Extended Warranty extends your warranty for an additional two years. Already have a CyberData device and want to add a Two-Year Warranty? Please click the link below to register your device first:

https://support.cyberdata.net/portal/en/newticket

CyberData’s Try & Buy program allows you to order QTY (1) of any SIP device and try it for 30 days to determine if it will meet your needs. When “Try and Buy" is selected, we charge on shipment and we will apply a credit IF the product is returned through our RMA process within 30 days, in good condition in its original packaging.

Once returned and upon inspection, CyberData will apply the credit to your credit card, less any shipping and handling charges that CyberData incurs. No returns are accepted after 30 days under our Try & Buy program.

Need help configuring your devices?

Now up to 38% brighter and upgraded to an IP66 rating, the wall-mounted InformaCast Enabled Outdoor RGB (Multi-Color) Strobe operates as a powerful and highly effective visual alerting device.

In InformaCast mode, when an audio page is sent to the Strobe, a specific color, brightness and blink rate can be selected based on the priority of the page. The Strobe supports 10 InformaCast priority levels*.

In the SIP mode, the device can be set up as part of a ring group or call group to give visual notification of incoming calls or pages. You can have the Strobe respond to message waiting signals by blinking. When the message has been heard, the Strobe stops blinking.

The Outdoor Strobe may also be activated by being part of a multicast group. The Strobe can be configured with up to 10 multicast addresses and is activated when a stream is sent to its address. Users may also use CyberData's HTTP command set to directly access the Strobe's functions.

*InformaCast v9.0.1 or higher is required to take advantage of this feature.

  • Compatible with Singlewire InformaCast v12.1, including support for downloading SIP credentials from InformaCast
  • Compatible with Cisco Call Manager
  • Meets ADA requirements for telephony signaling and notification
  • SIP and multicast activation
  • For each activation, the user can choose among multiple colors, blink rates, and brightness levels
  •

  • Event-controlled relay
  • Tamper sensor
  •

  • TLS 1.2, enhanced security for IP Endpoints in a local or cloud-based environment
  • Autoprovisioning via HTTPS, HTTP or TFTP
  • HTTPS or HTTP web based configuration. HTTPS is enabled by default
  • Configurable event generation for device health and status monitoring
  • 802.11q VLAN tagging
  • HTTP Command Interface
  • Support for Cisco SRST resiliency
  •

    Use Areas Include:

    • Shipping and receiving areas
    • Parking garages and parking lots
    • Socially Distanced Outdoor Gathering Areas
    • Outdoor school amphitheaters, stadiums and playgrounds
    • Anyplace needing an IP rated outdoor visual alert
      Ethernet I/F 10/100 Mbps
      Protocol SIP RFC 3261 Compatible
      Notification Software Singlewire InformaCast v4.0 and above
      Power Input PoE 802.3af compliant or +8 to +12VDC @ 1000mA Regulated Power Supply (not included)
      Flash Rate 5 user-defined scenes
      LED MTBF 100,000 Hours
      Brightness 366 Lux (white color)
      On-Board Relay 1A @ 30 VDC
      Network Security TLS/SSL 1.2
      IP Rating IP66
      Operating Range Temperature: -40 degrees C to 55 degrees C (-40 degrees F to 131 degrees F)
      Humidity: 5-95%, non-condensing
      Storage Temperature -40 degrees C to 70 degrees C (-40 degrees F to 158 degrees F)
      Storage Altitude Up to 15,000 ft. (4573 m)
      Dimensions* 5.1 inches [129.5 mm] Length
      2.9 inches [73.66 mm] Width
      5.1 inches [129.5 mm] Height
      Weight
      Boxed Weight
      2.0 lbs. [0.90 kg]
      3.0 lbs. [1.35 kg]
      Compliance CE; EMC Directive – Class A EN 55032 & EN 55024, LV Safety Directive – EN 60950-1 and EN 62368-1, RoHS Compliant, FCC; Part 15 Class A, Industry Canada; ICES-3 Class A, IEEE 802.3 Compliant; TAA Compliant
      Warranty 2 years Limited
      Part Number 011489

      *Dimensions are measured from the perspective of the product being upright with the front of the product facing you.

      What is multicast?

      IP multicast is a technique for one-to-many communication over a local IP network. IGMP multicast is sent via UDP packets from a multicast server to a multicast receiver. This stream scales to a larger receiver population by not requiring prior knowledge of who or how many receivers there are. Multicast uses network infrastructure efficiently by requiring the source to send a packet only once, even if it needs to be delivered to many receivers. The network replicates the packet in order to reach multiple receivers only when necessary.

      Multicast is a great alternative to SIP registration as it does not require that the recipient of the stream to register as an extension on an IP-PBX server.

      CyberData products support both regular IGMP multicast as well as proprietary Polycom Group Paging.

      I have a Cisco 6513 switch. When I plug in a CyberData VoIP device, the device constantly reboots and will not register to the SIP server.

      Please adjust the switch power selection to Power inline static, as opposed to Power inline dynamic. This will allow the device to continuously receive 15.4W of power.

      I have a Cisco Catalyst series switch. How do I set the unit so that it can use PoE (under 15.4w) instead of an external power source?

      There are known PoE limitations with third party devices on the Cisco Catalyst series switches. This includes the 2500, 3500, and 6500 series switches. It's important to keep in mind that CyberData devices are considered third party devices and require switch port setting adjustments. Be sure to turn power policing off if it has been enabled on your switch. Power policing is disabled by default. Also, configure your port for no shutdown. Use the following command to configure inline power: power inline static max 15400.

      What IP phones do you recommend for setting up a Peer to Peer with this device?
      I need to install a CyberData Strobe outdoors. Is there a dome enclosure that can be used with your strobes and if so, what is the part#?

      We recommend the dome enclosure made by Safety Technology International <https://www.sti-usa.com> PN: STI-1229-HAZ

      Typical Installation

      Dimensions and Rear View with Mounting Holes

      Dimensions

      Mounting

      Cable Routing and Wall Mounting Option
      Side Conduit Mounting Restrictions

      Onboard Terminal Connections

      Connections


      Remote Switch Connection

      Description

      Now up to 38% brighter and upgraded to an IP66 rating, the wall-mounted InformaCast Enabled Outdoor RGB (Multi-Color) Strobe operates as a powerful and highly effective visual alerting device.

      In InformaCast mode, when an audio page is sent to the Strobe, a specific color, brightness and blink rate can be selected based on the priority of the page. The Strobe supports 10 InformaCast priority levels*.

      In the SIP mode, the device can be set up as part of a ring group or call group to give visual notification of incoming calls or pages. You can have the Strobe respond to message waiting signals by blinking. When the message has been heard, the Strobe stops blinking.

      The Outdoor Strobe may also be activated by being part of a multicast group. The Strobe can be configured with up to 10 multicast addresses and is activated when a stream is sent to its address. Users may also use CyberData's HTTP command set to directly access the Strobe's functions.

      *InformaCast v9.0.1 or higher is required to take advantage of this feature.

      Features

    • Compatible with Singlewire InformaCast v12.1, including support for downloading SIP credentials from InformaCast
    • Compatible with Cisco Call Manager
    • Meets ADA requirements for telephony signaling and notification
    • SIP and multicast activation
    • For each activation, the user can choose among multiple colors, blink rates, and brightness levels
    •

    • Event-controlled relay
    • Tamper sensor
    •

    • TLS 1.2, enhanced security for IP Endpoints in a local or cloud-based environment
    • Autoprovisioning via HTTPS, HTTP or TFTP
    • HTTPS or HTTP web based configuration. HTTPS is enabled by default
    • Configurable event generation for device health and status monitoring
    • 802.11q VLAN tagging
    • HTTP Command Interface
    • Support for Cisco SRST resiliency
    •

      Use Areas Include:

      • Shipping and receiving areas
      • Parking garages and parking lots
      • Socially Distanced Outdoor Gathering Areas
      • Outdoor school amphitheaters, stadiums and playgrounds
      • Anyplace needing an IP rated outdoor visual alert

        Specs

        Ethernet I/F 10/100 Mbps
        Protocol SIP RFC 3261 Compatible
        Notification Software Singlewire InformaCast v4.0 and above
        Power Input PoE 802.3af compliant or +8 to +12VDC @ 1000mA Regulated Power Supply (not included)
        Flash Rate 5 user-defined scenes
        LED MTBF 100,000 Hours
        Brightness 366 Lux (white color)
        On-Board Relay 1A @ 30 VDC
        Network Security TLS/SSL 1.2
        IP Rating IP66
        Operating Range Temperature: -40 degrees C to 55 degrees C (-40 degrees F to 131 degrees F)
        Humidity: 5-95%, non-condensing
        Storage Temperature -40 degrees C to 70 degrees C (-40 degrees F to 158 degrees F)
        Storage Altitude Up to 15,000 ft. (4573 m)
        Dimensions* 5.1 inches [129.5 mm] Length
        2.9 inches [73.66 mm] Width
        5.1 inches [129.5 mm] Height
        Weight
        Boxed Weight
        2.0 lbs. [0.90 kg]
        3.0 lbs. [1.35 kg]
        Compliance CE; EMC Directive – Class A EN 55032 & EN 55024, LV Safety Directive – EN 60950-1 and EN 62368-1, RoHS Compliant, FCC; Part 15 Class A, Industry Canada; ICES-3 Class A, IEEE 802.3 Compliant; TAA Compliant
        Warranty 2 years Limited
        Part Number 011489

        *Dimensions are measured from the perspective of the product being upright with the front of the product facing you.

        FAQs

        What is multicast?

        IP multicast is a technique for one-to-many communication over a local IP network. IGMP multicast is sent via UDP packets from a multicast server to a multicast receiver. This stream scales to a larger receiver population by not requiring prior knowledge of who or how many receivers there are. Multicast uses network infrastructure efficiently by requiring the source to send a packet only once, even if it needs to be delivered to many receivers. The network replicates the packet in order to reach multiple receivers only when necessary.

        Multicast is a great alternative to SIP registration as it does not require that the recipient of the stream to register as an extension on an IP-PBX server.

        CyberData products support both regular IGMP multicast as well as proprietary Polycom Group Paging.

        I have a Cisco 6513 switch. When I plug in a CyberData VoIP device, the device constantly reboots and will not register to the SIP server.

        Please adjust the switch power selection to Power inline static, as opposed to Power inline dynamic. This will allow the device to continuously receive 15.4W of power.

        I have a Cisco Catalyst series switch. How do I set the unit so that it can use PoE (under 15.4w) instead of an external power source?

        There are known PoE limitations with third party devices on the Cisco Catalyst series switches. This includes the 2500, 3500, and 6500 series switches. It's important to keep in mind that CyberData devices are considered third party devices and require switch port setting adjustments. Be sure to turn power policing off if it has been enabled on your switch. Power policing is disabled by default. Also, configure your port for no shutdown. Use the following command to configure inline power: power inline static max 15400.

        What IP phones do you recommend for setting up a Peer to Peer with this device?
        I need to install a CyberData Strobe outdoors. Is there a dome enclosure that can be used with your strobes and if so, what is the part#?

        We recommend the dome enclosure made by Safety Technology International <https://www.sti-usa.com> PN: STI-1229-HAZ

        Installation

        Typical Installation

        Dimensions and Rear View with Mounting Holes

        Dimensions

        Mounting

        Cable Routing and Wall Mounting Option
        Side Conduit Mounting Restrictions

        Onboard Terminal Connections

        Connections


        Remote Switch Connection
