011511 VoIP SIP/Multicast Ceiling Mount Speaker

Part Number: 011511

MSRP: $389.00

Each CyberData device comes with a Two-Year Warranty. Extended Warranty extends your warranty for an additional two years. Already have a CyberData device and want to add a Two-Year Warranty? Please click the link below to register your device first:

https://support.cyberdata.net/portal/en/newticket

CyberData’s Try & Buy program allows you to order QTY (1) of any SIP device and try it for 30 days to determine if it will meet your needs. When “Try and Buy" is selected, we charge on shipment and we will apply a credit IF the product is returned through our RMA process within 30 days, in good condition in its original packaging.

Once returned and upon inspection, CyberData will apply the credit to your credit card, less any shipping and handling charges that CyberData incurs. No returns are accepted after 30 days under our Try & Buy program.

Need help configuring your devices?

The CyberData VoIP SIP/Multicast Wall Mount Speaker is a highly cost-effective Power-over-Ethernet (PoE 802.3af)
and Voice-over-IP (VoIP) public address indoor speaker that easily connects into existing local area networks with a
single Ethernet cable connection.

The speaker plays multicast messages, independent of the SIP environment. The device’s streamlined case and
included mounting hardware offers an easy installation in almost any environment.

CyberData’s SIP-enabled VoIP products are compatible with a vast majority of VoIP systems including SBCs, Gateways,
and phone systems both on-premise or cloud-based.

  • Simultaneous SIP and multicast
  • Paging prioritization
  • Can receive pages directly from Poly phones as well as other devices that can send standard multicast
  • Loud/Night Ringer function - second SIP extension
  • Support for 10 multicast paging groups
  • Network-adjustable speaker volume
  • High-efficiency speaker driver
  • Small footprint
  • TLS 1.2 (includes mutual authentication) and SRTP enhanced security for IP Endpoints in a local or
    cloud-based environment
  • Autoprovisioning via HTTP, HTTPS, or TFTP
  • HTTPS or HTTP web-based configuration. HTTPS is enabled by default
  • 802.11q VLAN tagging
  • Configurable event generation for device health and status monitoring
  • Web-based upgradeable firmware
  • Support for multiple SIP servers for redundancy
Ethernet I/F 10/100 Mbps
Protocol RTP, SIP (RFC 3261)
Power Input PoE 802.3af
Audio Output 802.3af - SPL 99 dB @ 1 meter
Payload Types G.711 a-law, G.711 μ-law, G.722, and G.729
Network Security TLS 1.2, SRTP, HTTPS
Operating Range Temperature: -40 degrees C to 55 degrees C (-40 degrees F to 131 degrees F)
Humidity: 5-95%, non-condensing
Storage Temperature -40 degrees C to 70 degrees C (-40 degrees F to 158 degrees F)
Storage Altitude Up to 15,000 ft. (4573 m)
Dimensions 7.93 in. [201.5 mm] Grill Diameter
6.70 in. [170 mm] Can Diameter
3.52 in. [89.4 mm] Can Depth
Weight
Boxed Weight
2.4 lbs [1.09 kg]
2.9 lbs [1.32 kg]
Compliance CE: EMC Directive – Class A EN 55032 & EN 55024,
LV Safety Directive EN 62368-1; RoHS Compliant;
FCC Part 15 Class A; Industry Canada ICES-3 Class A;
IEEE 802.3 Compliant; TAA Compliant
Warranty 2 Years Limited
Part Number 011511

*Dimensions are measured from the perspective of the product being upright with the front of the product facing you.

Where should I install this product?

The SIP Speakers are designed for a quieter environment such as a classroom, hallway, or office. If you need a speaker for a high noise/harsh conditions environment such as a warehouse floor or a school field, we instead recommend the 011457 SIP IP66 Outdoor Horn. In the case of requiring two-way audio like our SIP Talk-Back Speaker provides, the CyberData Intercoms may be a better choice for a louder environment. Please contact our sales team for more information.

How do I update my firmware?

Go to the Downloads tab, click on the serial number range matching your device and download the firmware compatible with it. To update the firmware, unzip the file and log in to the web GUI for the device you are trying to upgrade. Navigate to the Firmware tab and browse for the firmware file you just downloaded. Select and upload that file. Do not reboot, the device will do it for you. For more information, please check your product’s Operations Guide, also available under the Downloads tab.

PLEASE NOTE: If you are downgrading, please contact CyberData’s Technical Support Department first to ensure the device does not get damaged. We also recommend you export a copy of your current configuration BEFORE updating, should a loss of power or another issue occur that would potentially lose your settings.

Is this device compatible with my service provider or IP-PBX server?

CyberData VoIP products are compatible with IP-PBX servers that support standard SIP protocol. You can find a full list of IP-PBX servers that CyberData products have been validated on by going to Connecting to Compatible IP-PBX Servers. If you do not see your IP-PBX on this list, feel free to contact CyberData’s Technical Support Department for more information.

What is multicast?

IP multicast is a technique for one-to-many communication over a local IP network. IGMP multicast is sent via UDP packets from a multicast server to a multicast receiver. This stream scales to a larger receiver population by not requiring prior knowledge of who or how many receivers there are. Multicast uses network infrastructure efficiently by requiring the source to send a packet only once, even if it needs to be delivered to many receivers. The network replicates the packet in order to reach multiple receivers only when necessary.

Multicast is a great alternative to SIP registration as it does not require that the recipient of the stream to register as an extension on an IP-PBX server.

CyberData products support both regular IGMP multicast as well as proprietary Polycom Group Paging.

What accessories does this speaker support?

This speaker was designed to work independently and does not currently support any CyberData accessory products.

For additional support or answers to questions not covered on this page, who should I contact?

Typical Installation

Mounting

Dimensions

Disassemble the Speaker

Description

The CyberData VoIP SIP/Multicast Wall Mount Speaker is a highly cost-effective Power-over-Ethernet (PoE 802.3af)
and Voice-over-IP (VoIP) public address indoor speaker that easily connects into existing local area networks with a
single Ethernet cable connection.

The speaker plays multicast messages, independent of the SIP environment. The device’s streamlined case and
included mounting hardware offers an easy installation in almost any environment.

CyberData’s SIP-enabled VoIP products are compatible with a vast majority of VoIP systems including SBCs, Gateways,
and phone systems both on-premise or cloud-based.

Features

  • Simultaneous SIP and multicast
  • Paging prioritization
  • Can receive pages directly from Poly phones as well as other devices that can send standard multicast
  • Loud/Night Ringer function - second SIP extension
  • Support for 10 multicast paging groups
  • Network-adjustable speaker volume
  • High-efficiency speaker driver
  • Small footprint
  • TLS 1.2 (includes mutual authentication) and SRTP enhanced security for IP Endpoints in a local or
    cloud-based environment
  • Autoprovisioning via HTTP, HTTPS, or TFTP
  • HTTPS or HTTP web-based configuration. HTTPS is enabled by default
  • 802.11q VLAN tagging
  • Configurable event generation for device health and status monitoring
  • Web-based upgradeable firmware
  • Support for multiple SIP servers for redundancy

Specs

Ethernet I/F 10/100 Mbps
Protocol RTP, SIP (RFC 3261)
Power Input PoE 802.3af
Audio Output 802.3af - SPL 99 dB @ 1 meter
Payload Types G.711 a-law, G.711 μ-law, G.722, and G.729
Network Security TLS 1.2, SRTP, HTTPS
Operating Range Temperature: -40 degrees C to 55 degrees C (-40 degrees F to 131 degrees F)
Humidity: 5-95%, non-condensing
Storage Temperature -40 degrees C to 70 degrees C (-40 degrees F to 158 degrees F)
Storage Altitude Up to 15,000 ft. (4573 m)
Dimensions 7.93 in. [201.5 mm] Grill Diameter
6.70 in. [170 mm] Can Diameter
3.52 in. [89.4 mm] Can Depth
Weight
Boxed Weight
2.4 lbs [1.09 kg]
2.9 lbs [1.32 kg]
Compliance CE: EMC Directive – Class A EN 55032 & EN 55024,
LV Safety Directive EN 62368-1; RoHS Compliant;
FCC Part 15 Class A; Industry Canada ICES-3 Class A;
IEEE 802.3 Compliant; TAA Compliant
Warranty 2 Years Limited
Part Number 011511

*Dimensions are measured from the perspective of the product being upright with the front of the product facing you.

FAQs

Where should I install this product?

The SIP Speakers are designed for a quieter environment such as a classroom, hallway, or office. If you need a speaker for a high noise/harsh conditions environment such as a warehouse floor or a school field, we instead recommend the 011457 SIP IP66 Outdoor Horn. In the case of requiring two-way audio like our SIP Talk-Back Speaker provides, the CyberData Intercoms may be a better choice for a louder environment. Please contact our sales team for more information.

How do I update my firmware?

Go to the Downloads tab, click on the serial number range matching your device and download the firmware compatible with it. To update the firmware, unzip the file and log in to the web GUI for the device you are trying to upgrade. Navigate to the Firmware tab and browse for the firmware file you just downloaded. Select and upload that file. Do not reboot, the device will do it for you. For more information, please check your product’s Operations Guide, also available under the Downloads tab.

PLEASE NOTE: If you are downgrading, please contact CyberData’s Technical Support Department first to ensure the device does not get damaged. We also recommend you export a copy of your current configuration BEFORE updating, should a loss of power or another issue occur that would potentially lose your settings.

Is this device compatible with my service provider or IP-PBX server?

CyberData VoIP products are compatible with IP-PBX servers that support standard SIP protocol. You can find a full list of IP-PBX servers that CyberData products have been validated on by going to Connecting to Compatible IP-PBX Servers. If you do not see your IP-PBX on this list, feel free to contact CyberData’s Technical Support Department for more information.

What is multicast?

IP multicast is a technique for one-to-many communication over a local IP network. IGMP multicast is sent via UDP packets from a multicast server to a multicast receiver. This stream scales to a larger receiver population by not requiring prior knowledge of who or how many receivers there are. Multicast uses network infrastructure efficiently by requiring the source to send a packet only once, even if it needs to be delivered to many receivers. The network replicates the packet in order to reach multiple receivers only when necessary.

Multicast is a great alternative to SIP registration as it does not require that the recipient of the stream to register as an extension on an IP-PBX server.

CyberData products support both regular IGMP multicast as well as proprietary Polycom Group Paging.

What accessories does this speaker support?

This speaker was designed to work independently and does not currently support any CyberData accessory products.

For additional support or answers to questions not covered on this page, who should I contact?

Installation

Typical Installation

Mounting

Dimensions

Disassemble the Speaker
